P. LEO ELECTRICAL INSULATION SYSTEM, UL File E200050
(click on a System to view details)

  Designation

Class

Voltage

B81

130(B)

600V

B82

130(B)

600V

B83

130(B)

600V

B85

130(B)

600V

B86

130(B)

600V

B88

130(B)

600V

B89

130(B)

600V

B90

130(B)

600V

B91

130(B)

600V

B92

130(B)

600V

B93

130(B)

600V

B95
130(B)
600V
B96
130(B)
600V
B97
130(B)
600V
B98-Table I
130(B)
600V
B98-Table II
130(B)
600V
F81

155(F)

600V

F82

155(F)

600V

F83

155(F)

600V

F88

155(F)

600V

F89

155(F)

600V

F90
155(F)
600V
F91
155(F)
600V
H82

180(H)

600V

H83

180(H)

600V

H84

180(H)

600V

H85

180(H)

600V

H86

180(H)

600V

H87

180(H)

600V

HV-1

220(R)

15KV

HV-2

220(R)

34.5KV

N82

200(N)

600V

N83

200(N)

600V

N85

200(N)

600V

N86

200(N)

600V

N88

200(N)

600V

N89

200(N)

600V

N90

200(N)

600V

N91

200(N)

600V

R81

220(R)

600V

R82

220(R)

600V
